Softgel Encapsulation Machines
You are here:
Softgel encapsulation machines fill airtight gelatin shells with semi-solids or liquids. Encap’s machines offer high reliability and comprehensive installation and after-sales support.
ATTRIBUTES
- Large touch screen with fault diagnostic and operating parameter presets
- Constructed with premium aviation aluminum alloy
- Fast and stable pneumatic mold pressing
- Independent, variable drive motor for low-noise and smooth operation
- Gelatin sheet cooling mechanism with low energy consumption
- Adjustable material hopper for different product requirements
- User-friendly design for easy operation and maintenance
HMI Interface
The machine is equipped with a user-friendly HMI interface, making it easy to operate and control. This intuitive design simplifies setup and monitoring, reducing training time for operators and increasing overall efficiency.
Heated Material Hopper
The softgel encapsulation machine includes a heated material hopper, which is ideal for handling heat-sensitive or viscous raw materials. This feature ensures that the ingredients remain at optimal temperatures for uniform encapsulation and prevents clogging or inconsistencies in the gel mass.
High-Precision Mold Processing
The machine uses high-precision molds to ensure smooth production and seamless encapsulation. This level of accuracy not only improves the quality of the softgels but also extends the lifespan of the molds, reducing maintenance costs and increasing overall production reliability.
Sensor-Controlled Feeding System
A sensor-controlled feeding system in the spreader box automatically regulates the flow of materials. This advanced feature ensures consistent filling and reduces product waste, enhancing the efficiency of the encapsulation process.
Integrated Air Conveyance System
The machine features an integrated fan system that facilitates the smooth transport of softgel capsules. This setup simplifies equipment layout, reduces the risk of product damage, and ensures efficient handling of the softgels throughout the production line.
Teflon-Coated Injectors
The injectors are coated with Teflon to prevent sticking and extend their lifespan. This coating enhances the durability of the injectors and maintains optimal performance over long production runs, minimizing downtime for maintenance.
High-Precision Piston Pump
Equipped with high-precision piston pumps, the machine ensures accurate and consistent dosing of the fill material into the softgel capsules. This precision is crucial for maintaining product uniformity, which is essential in pharmaceutical and nutraceutical applications.
Enhanced Benefits of Encap's Softgel Encapsulation Machine
Encap’s softgel encapsulation machine provides a combination of precision, reliability, and user-friendly operation, making it an ideal solution for businesses looking to improve their softgel production process with high efficiency and consistent quality.
TECHNICAL PARAMETERS
| CF-Q 7500B/C/E | ||||
|---|---|---|---|---|
| Model | RG0.8-110C | RG2-200C | RG2-250C | RG2-300C |
| Roller Die Rated Speed | 0~7r/min | 0~7r/min | 0~5r/min | 0~5r/min |
| Roller Die Size | Ф72×110mm | Ф103×200mm | Ф150×250mm | Ф150×250mm |
| Single Piston Feeding Volume | 0~0.8ml | 0~2ml | 0~2ml | 0~2ml |
| Dimensions | 1500×860×1700 mm | 1990×1040×2100 mm | 2420×1200×2200 mm | 2420×1250×2200 mm |
| Weight | 700kg | 1000kg | 1800kg | 1900kg |
| Total Power | 3.13kw | 4.75kw | 7.55kw | 8.15kw |
| CF-Q 7500B/C/E | ||
|---|---|---|
| Model | RG0.8-110C | RG2-200C |
| Roller Die Rated Speed | 0~7r/min | 0~7r/min |
| Roller Die Size | Ф72×110mm | Ф103×200mm |
| Single Piston Feeding Volume | 0~0.8ml | 0~2ml |
| Dimensions | 1500×860×1700 mm | 1990×1040×2100 mm |
| Weight | 700kg | 1000kg |
| Total Power | 3.13kw | 4.75kw |
| CF-Q 7500B/C/E | ||
|---|---|---|
| Model | RG2-250C | RG2-300C |
| Roller Die Rated Speed | 0~5r/min | 0~5r/min |
| Roller Die Size | Ф150×250mm | Ф150×250mm |
| Single Piston Feeding Volume | 0~2ml | 0~2ml |
| Dimensions | 2420×1200×2200 mm | 2420×1250×2200 mm |
| Weight | 1800kg | 1900kg |
| Total Power | 7.55kw | 8.15kw |
| CF-Q 7500B/C/E | |
|---|---|
| Power Supply | 380V; 50Hz |
| Noise | ＜75dBA |
SEE THE MACHINE IN ACTION
CONTACT US TODAY TO LEARN MORE
Ready to elevate your production capabilities? Contact Encap North America today to speak with one of our experts. We’ll provide you with all the information you need, including a personalized consultation to determine how our extensive range of machinery and equipment can meet your specific needs. Request a quote, schedule a virtual demo, or download our detailed product brochure to get started.
