Multifunctional Fluid Bed Granulator
(DPL Series)
Multifunctional Fluid Bed Granulator
You are here:
A dedicated drying system that leverages high-efficiency fluidized technology to ensure uniform moisture removal without the granulation or coating subsystems.
- The DPL Series is a highly versatile, all-in-one processing system designed for advanced pharmaceutical and chemical production.
- It seamlessly integrates multiple processes—including mixing, drying, top-spray granulation, and bottom-spray pellet coating—into a single, compact unit.
- Pharmaceutical Industry: Essential for sophisticated solid dosage forms requiring multi-stage processing, such as delayed-release pellets or specialized granulation.
- Chemical & Food Industries: Highly effective for specialized coating and granulation applications where material uniformity and process control are critical.
Features and Benefits
- Multifunctional Design: Combines mixing, drying, granulation, and coating in one machine, significantly reducing floor space requirements and equipment investment.
- Precision Coating Capabilities: Specifically engineered with bottom-spray technology for uniform pellet coating, ensuring high-quality functional film application.
- Process Flexibility: Allows for seamless switching between different processing modes, making it an ideal solution for facilities handling diverse product lines.
- Regulatory Compliance: Engineered to fully meet FDA, cGMP, and GMP standards.
- Safety Integration: Features robust explosion-proof systems (anti-10 or 12 bar) to ensure operational safety when handling potent or volatile materials.
Volume Range:
Effective volume for granulation and drying ranges from 90L – 860 L, and for coating from 80L – 760 L.
Batch Capacity:
Granulation and drying capacities range from 14 kg – 300 kg per batch, with specialized coating capacities ranging from 12 kg – 190 kg per batch.
Heating Modes:
Two alternative modes available, including electric heating or steam heating.
Control System:
PID precision control system utilized, with optional compliance for 21 CFR Part 11 requirements.
Advanced Options:
Systems are available with WIP, PAT, final dedusting, and dehumidifier systems.
TECHNICAL PARAMETERS
| DPL Series | |
|---|---|
| Specification | Details |
| Effective volume (Coating) | 80 L - 760 L |
| Effective volume (Granulation & Drying) | 90 L - 860 L |
| Total power | 11 kW - 37 kW |
| Steam pressure | 0.4 - 0.6 MPa |
| Steam consumption | 144 - 410 kg/h |
| Compressed air pressure | 0.6 - 0.8 MPa |
| Compressed air consumption | 0.6 - 3 m3/min |
| Heating temperature range | Room temperature - 120 °C |
| CF-Q 7500B/C/E | |||||
|---|---|---|---|---|---|
| Model | DPL-30 | DPL-60 | DPL-120 | DPL-200 | DPL-300 |
| Main machine weight (kg) | 1200 | 1600 | 1800 | 2300 | 2500 |
| Auxiliary machine Weight (kg) | 2790 | 3280 | 4020 | 3820 | 4050 |
| Dimensions (mm) | 722×984 ×3374 | 1022×1340 ×4353 | 1024×1540 ×4980 | 1378×1540 ×5040 | 1580×1840 ×5865 |
Product references: DPL-30 / DPL-60 / DPL-120 / DPL-200 / DPL-300 MODELS
