Single-Column Bin Blender
You are here:
The CSC Series Single-Column Bin Blender is widely used for mixing different components such as powders with powders, powders with granules and granules with granules within pharmaceutical production procedures.. The machine has functions such as automatic lifting, mixing and lowering. It can be equipped with various specifications of bin for mixing operations. It is suitable for mixing medicines of different varieties and different batches for large and medium-sized pharmaceutical enterprises according to process requirements. Multiple purposes can be realized in one machine.
ATTRIBUTES
- The product is a mechanically and electrically integrated high- tech product. It adopts hydraulic lifting, hydraulic driving and PLC control, with simple control and convenient adjustment of process parameters.
- Excellent control system sensitivity, compact machine structure and stable and reliable operation.
- The mixing barrel can serve both as the dispensing barrel for the previous procedure and as the feeding bin for the next procedure.
- The mixing evenness is above 99%, and the barrel inside is mirror polished and can be cleaned without any dead corners.
TECHNICAL PARAMETERS
| CF-Q 7500B/C/E | ||
|---|---|---|
| Model | CSC-300 | CSC-600 |
| Volume | 300L | 600L |
| Charge ratio | 0.3-0.8 | 0.4-0.8 |
| Max. Volume of Charge | 240L | 480L |
| Max. Production Capacity (according to bulk density 0.5) | 120kg | 300kg |
| Mixing motor power | 3.0kW | 5.5kW |
| Rotation speed of stirring | 3-20rpm | 3-12rpm |
| Lifting motor power | 3.0kW | 3.0kW |
| Weight | 1400kg | 1800kg |
| Height of the discharge port off the ground | ≥750mmOr customized | ≥750mmOr customized |
| Dimension | 2580×1960×2575 mm | 3250×2400×2825 mm |
Product references: CSC-300 / CSC-600 MODELS
